ZYHOBBY 8kg Airplane Nose/Main Wheel Servoless Electric Retracts for Landing Gear

Specification

No. PZ-15096SN Nose Retract

• GearSize: 93*51*30.8mm(L*W*H)
• Weight: 94g
• Speed: 6S/90°@4.8V; 5S/90°@6.0V, 4S/90°@7.4V
• Torque: 15.5kg-cm@4.8V: 18.6kg-cm@6.0V: 20.6kg-cm@7.4V
• Operating Voltage: 4.8V-6V
• Landing Struct Diameter: Φ 5mm
• Support Flight Weight: 8kg
• Wire Length: 420mm
• Wire Color: Brown, Red, Orange
• Plug Type: JR Plug

No. PZ-15096SM Main Retract

• Size: 93*51*30.8(L*W*H)
• Weight: 94g
• Speed: 6S/90°@4.8V; 5S/90°@6.0V, 4S/90°@7.4V
• Torque: 15.5kg-cm@4.8V: 18.6kg-cm@6.0V: 20.6kg-cm@7.4V
• Operating Voltage: 4.8V-7.4V
• Landing Struct Diameter: Φ 5mm
• Support Flight Weight: 8kg
• Wire Length: 420mm
• Wire Color: Brown, Red, Orange
• Plug Type: JR Plug

No. PZ-15096  Retract without Struct
Giant Landing Gears with Metal Block
Size(L*W*H):92.2*51*36mm
Weight: 88.8g/3.1oz
Speed: 6s/90°at 4.8v; 5s/90° at 6v; 4s/90° at 7.4v
Torque: 15.5kg-cm at 4.8v ; 18.6kg-cm at 6v; 20.6kg-cm at 7.4V
215oz-in at 4.8v ; 258oz-in at 6v; 286oz-in at 6v
Support Struct Diameter: 5mm
Support Flight Weight 8kg
Operating Voltage: 4.8v-7.4v
Wire Length: 300mm
Plug Type: JR Plug
Excellent for 120 class RC planes!
